Push Load: 1000N, 750N, 500N, 250N, 125N, 70N
Pull Load: 1000N, 750N, 500N, 250N, 125N, 70N
Color: Silver Gray
Protection Class (IP Rating): Maximum IPX6
Stroke Length:
-
Standard and Dual Hall Sensor: 25–1020 mm (increments of 4 mm)
-
With Potentiometer:
• 1000N: 25–520 mm (increments of 4 mm)
• 750N: 25–800 mm (increments of 4 mm)
• ≤500N: 25–1000 mm (increments of 4 mm)
Standard Installation Dimensions (Customizable):
-
Standard and Dual Hall Sensor:
• L = S + 110 (25 ≤ S ≤ 610 mm)
• L = S + 125 (610 < S ≤ 765 mm)
• L = S + 145 (765 < S ≤ 1000 mm) -
With Potentiometer:
• L = S + 145 (25 ≤ S ≤ 610 mm)
• L = S + 160 (610 < S ≤ 765 mm)
• L = S + 180 (765 < S ≤ 1000 mm)
Noise Level: ≤55 dB (ambient noise ≤40 dB)
Hall Sensor: Optional
Potentiometer: Optional
Limit Switch: Built-in
Weight: Approx. 1 kg (varies with stroke length and installation dimensions)
Static Bending Moment: Does not allow lateral loads
