Marine Mounts

Marine Mounts for Mobile and Maritime Applications

Marine Mounts are high-performance rubber-metal isolators engineered for mobile and marine environments, offering a natural frequency between 6.3 Hz and 13 Hz, with 7.8 Hz under maximum load. Designed for stability and longevity, these machine feet are maintenance-free, break-proof, and ready for immediate installation.

Their structure is optimized for challenging conditions: the longitudinal stiffness is 2.5 times the vertical stiffness, and the lateral stiffness is 75% of the vertical, ensuring superior resistance to dynamic forces from all directions. This makes Marine Mounts especially effective for diesel generators, ship engines, and energy production systems.

Built from zinc-plated steel with Neoprene or natural rubber cushioning, they are resistant to UV radiation and perform reliably in extreme climates ranging from -40 °C to +80 °C.

These isolators are ideal for use in off-road machinery, vibrators, crushing systems, power aggregates, and military-grade equipment, offering high resilience where stability and noise reduction are critical.
