HFT Series Wider air gripper
Lightweight and compact design
The HFT series is ideal for applications in packaging, automotive assembly, and material handling that require strong and stable parallel gripping.
The HFT Series Wide Parallel Air Gripper by AirTAC is designed for handling large or bulky workpieces with high gripping force and stability. This series is ideal for applications where greater opening and closing ranges are needed, providing a reliable solution for automation and robotic systems. The clamping force is increased thanks to the double-piston design, and a magnet is included in the standard configuration. The gripper opening or closing is precisely synchronised with the rack & pinion mechanism.
- Bore size: from 10mm to 32mm - 5 sizes available
- Stroke (both jaws): from 20mm to 150mm
- Gripping force: from 14N to 228N
- Maximum frequency: 40 cycles/min
- Working pressure: 1.5~7bar (0.15MPa~0.7Mpa)
